Gate valves
Уточнювати
- 10 продуктів на сторінку
- 25 продуктів на сторінку
- 50 продуктів на сторінку
- Актуальність
- Створений на
- Код товару
- Назва
- Доступний
-
TTV Valves
Product code: G229022.F4
TTV G229022 Resilient Seat Gate Valve (DIN 3202 F4) made of Ductile Iron, EPDM wedge for Wras Approved
-
Application
Drinking water, water treatment and supply and irrigation
-
Max. operating pressure
16 bars for PN16 flanged,
10 bars for PN10 flanged -
Body Design
Face-to-Face Standard ISO 5752 series 14. DIN 3202 F4
-
Body material
Ductile Iron GJS 400-15
-
Wedge
Vulcansied EPDM Ductile Iron
-
Working temperature
up to +120°C
-
Bonnet
Ductile Iron GJS 400-15
-
Shaft/stem material
Stainless Steel
-
Valve Approvals & Features
Wras Approved
-
Actuator Type
Handwheel, Steel Painted
-
Connections
Flanged EN 1092-2 PN10/16, face-to-face F4
-
-
TTV Valves
Product code: G229022.F5
TTV G229022 Resilient Seat Gate Valve (DIN 3202 F5) made of Ductile Iron, EPDM wedge for Wras Approved
-
Application
Drinking water, water treatment and supply and irrigation
-
Max. operating pressure
16 bars for PN16 flanged,
10 bars for PN10 flanged -
Body Design
Face-to-Face Standard ISO 5752 series 15. DIN 3202 F5
-
Body material
Ductile Iron GJS 400-15
-
Wedge
Vulcansied EPDM Ductile Iron
-
Working temperature
up to +120°C
-
Bonnet
Ductile Iron GJS 400-15
-
Shaft/stem material
Stainless Steel
-
Valve Approvals & Features
Wras Approved
-
Actuator Type
Handwheel, Steel Painted
-
Connections
Flanged EN 1092-2 PN10/16, face-to-face F5
-
-
TTV Valves
Product code: G229022.BS
TTV G229022 Resilient Seat Gate Valve (BS 5163) made of Ductile Iron, EPDM wedge for Wras Approved
-
Application
Drinking water, water treatment and supply and irrigation
-
Max. operating pressure
16 bars for PN16 flanged,
10 bars for PN10 flanged -
Body Design
Face-to-Face Standard ISO 5752 series 3. BS 5163
-
Body material
Ductile Iron GJS 400-15
-
Wedge
Vulcansied EPDM Ductile Iron
-
Working temperature
up to +120°C
-
Bonnet
Ductile Iron GJS 400-15
-
Shaft/stem material
Stainless Steel
-
Valve Approvals & Features
Wras Approved
-
Actuator Type
Handwheel, Steel Painted
-
Connections
Flanged BS 4504 PN10/16, face-to-face BS 5163
-
