ICP Valves
Product code: C800.A
Class 800 Forged Carbon Steel Gate Valve ICP C800-A
-
Application
steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 136,2 bar
-
Body Design
Rising Stem
-
Body material
Forged Steel ASTM A105
-
Seat & Wedge
Stainless steel ASTM A182 F6A + Stellite
-
Packing
Graphite
-
Working temperature
-29°C up to +425°C
-
Bonnet
Carbon steel A105N
-
Shaft/stem material
Martensitic Stainless Steel AISI 410
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Female threaded (NPT) ANSI B 1.20.1,
Socket weld (SW) ASME B16.11
-
-
ICP Valves
Product code: C800.I
Class 800 Forged Stainless Steel Gate Valve ICP C800-I
-
Application
Steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 110,3 bar
-
Body Design
Rising Stem
-
Body material
Stainless Steel ASTM A182 F316L
-
Seat & Wedge
Stainless Steel F316L + Stellite
-
Packing
Graphite
-
Working temperature
-50°C up to +450°C
-
Bonnet
Stainless Steel ASTM A182 F316L
-
Shaft/stem material
Stainless Steel F316L
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Female threaded (NPT) ANSI B 1.20.1,
Socket weld (SW) ASME B16.11
-
-
ICP Valves
Product code: C150.A.RF
Class 150 Forged Carbon Steel Gate Valve ICP C150-A
-
Application
steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 19,6 bar
-
Body Design
Rising Stem
-
Body material
Carbon steel A105N
-
Seat & Wedge
Stainless steel ASTM A276 410 + Stellite
-
Packing
Graphite
-
Working temperature
-29°C up to +425°C
-
Bonnet
Carbon steel A105N
-
Shaft/stem material
Martensitic Stainless Steel AISI 410
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Flanged ASME B16.5 Class 150
-
-
ICP Valves
Product code: C300.A.RF
Class 300 Forged Carbon Steel Gate Valve ICP C300-A
-
Application
steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 51,1 bar
-
Body Design
Rising Stem
-
Body material
Carbon steel A105N
-
Seat & Wedge
Stainless steel ASTM A276 410 + Stellite
-
Packing
Graphite
-
Working temperature
-29°C up to +425°C
-
Bonnet
Carbon steel A105N
-
Shaft/stem material
Martensitic Stainless Steel AISI 410
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Flanged ASME B16.5 Class 300
-
-
ICP Valves
Product code: C150.I
Class 150 Forged Stainless Steel Gate Valve ICP C150-I
-
Application
steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 15,9 bar
-
Body Design
Rising Stem
-
Body material
Stainless Steel ASTM A182 F316L
-
Seat & Wedge
Stainless Steel F316L + Stellite
-
Packing
Graphite
-
Working temperature
-50°C up to +450°C
-
Bonnet
Stainless Steel ASTM A182 F316L
-
Shaft/stem material
Stainless Steel F316L
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Flanged ASME B16.5 Class 150
-
-
ICP Valves
Product code: C300.I
Class 300 Forged Stainless Steel Gate Valve ICP C300-I
-
Application
steam, condensates, thermal oil, compressed air, inert gases, auxiliary process networks, and small-diameter chemical lines.
-
Max. operating pressure
Up to 41,4 bar
-
Body Design
Rising Stem
-
Body material
Stainless Steel ASTM A182 F316L
-
Seat & Wedge
Stainless Steel F316L + Stellite
-
Packing
Graphite
-
Working temperature
-50°C up to +450°C
-
Bonnet
Stainless Steel ASTM A182 F316L
-
Shaft/stem material
Stainless Steel F316L
-
Valve Approvals & Features
CE, ATEX approved. NACE MR0175. Conforms to API 602.
-
Actuator Type
Handwheel, Cast Iron A197 Painted
-
Connections
Flanged ASME B16.5 Class 300
-
