ADCATrol® Intelligent Electro-Pneumatic Positioner ADCA TZIDC-200 with flameproof enclosure

Specifications

  • Housing material

    Aluminium enclosure,
    without transparent window for LCD

  • Positioner Type

    Electro-Pneumatic

  • Product or Component Type

    Digital valve Control, Valve Positioner,
    mechanical position indicator, display,
    Safe Ex d, fail safe, fail freeze

  • Accession

    Mounting bracket

  • Operation temperature

    from -40 to +85 °C

  • Analog Input

    Nominal op. range 4 to 20 mA

  • Input pressure

    1,4 to 6 bar

  • IP rating

    IP 66 NEMA 4X

  • Supply voltage

    24 V DC (11 to 30 V DC)

  • Communication link

    Analog signal 4 to 20 mA,
    and HART communication

  • Explosion protection

    ATEX Ex d II C T4/T5/T6 Gb or,
    IECEx Ex d II C T4/T5/T6 Gb

  • SIL

    Yes

Documentation

Technical data sheet(s)

ADCATrol® Intelligent Electro-Pneumatic Positioner ADCA TZIDC-200 with flameproof enclosure

Product code: V18348

Available to Order

Price according to configuration

Choose your configuration
See all configuration
Ref.#.
ex. VAT
(INDICATIVE PRICE)

Quantity

-
+

No product configuration

The selected configuration has been added to the cart

Go to quotation request
DESCRIPTION

The ADCATrol TZIDC is a digital intelligent electronically configurable positioner with communication capabilities designed for mounting to pneumatic linear or rotary actuators. It features a compact design with a modular construction and excellent performance capabilities.

Fully automatic determination of the control parameters and adaptation to the final control element yield considerable time savings and an optimal control behaviour.

MAIN FEATURES

Low operating cost.
Compact and flexible design.
Easy to comission with user-friendly interface.
Increased shock and vibration resistance with gearless sensor activation.
Reliable and efficient, with integrated maintenance-friendly air filters.
Automatic adjustment of control parameters during operation.
Integrated mechanical position indicator.
Wide operating temperature range (-40 to +85 ºC).
Mounting onto any linear or rotary actuator.
Single or double acting.

OPTIONS AND ACCESSORIES

HART, Profibus PA or FOUNDATION Fieldbus-H1 communication.
ATEX and IECEx approvals. SIL2 certification.
Module for analog position feedback.
Digital position feedback with inductive proximity switches.
Digital position feedback with 24 V microswitches.
Positioner with remote sensor.
Attachment kit for linear actuators according to IEC 534/NAMUR and rotary actuators according to VDI/VDE 3845.
Connection manifold with gauges.
PC adapters for communication.
PC software for remote configuration and operation.

AVAILABLE MODELS:

TZIDC-200 – Incl. flameproof enclosure.
